Хибридни инверториREF: FlexCore Series
EENOVANCE FlexCore Series | 125 kW~1 MW / 261 kWh~2.088 Mwh
FlexCore Series is a modular liquid-cooled commercial & industrial energy storage system offering flexible configurations from 125 kW to 1 MW and 261 kWh to 2088 kWh. Designed for diverse energy applications, it features intelligent EMS, remote monitoring, and cluster-level battery management for efficient operation. Multi-level protection, including gas, water, and ventilation monitoring, enhances system safety and reliability. With its scalable architecture and integrated design, FlexCore helps businesses optimize energy costs, improve power resilience, and support renewable energy integration across industrial and commercial facilities. Compliance: Electrical cabinet: IEC 62477/IEC62109/IEC 61439 Battery cabinet:UN38.3 / IEC62619 / IEC63056/IEC60730/IEC61000/IEC62477
| Cell technology: | LiFePO₄ |
|---|---|
| Battery system rated capacity: | 261 kWh – 2088 kWh |
| MPPT Voltage Range | 150 – 950 Vdc |
| Maximum PV Input Current | 45 A |
Технически параметри
Cell technology:LiFePO₄
Battery system rated capacity:261 kWh – 2088 kWh
MPPT Voltage Range150 – 950 Vdc
Maximum PV Input Current45 A
Battery Voltage Range728 – 936 V
Maximum Charging/Discharging Rate0.5 P
Cooling MethodBattery: Intelligent Liquid Cooling Electrical Cabinet: Intelligent Air Cooling
Operating Temperature-25°C to +45°C
Working Environment Humidity0–95% RH (Non-condensing)
Ingress ProtectionIP54
ComplianceUN38.3, IEC62619, IEC63056, IEC62477, IEC62109, IEC61000
// Системна интеграция
Поискай комплектна офертаНеобходима ли е индивидуална конфигурация?
Нашите инженери могат да оразмерят и комплектоват хибридни инвертори спрямо вашето специфично потребление и изисквания.
